Deep hole boring tools
Pneumatic Boring Tools
| NO | Boring dia | Center cutters | Nuts | Wrench | NO | Boring dia | Outside cutters | Nuts | Wrench |
| 1 | 25.00-28.70 | 800-05 03 08M-C-G | M2*10 | T6 | 1 | 25.00-31.00 | 800-05 03 08M-I-G | M2*10 | T6 |
| 2 | 28.71-33.99 | 800-06 T3 08M-C-G | M2*10 | T6 | 2 | 31.01-34.99 | 800-06 T3 08M-I-G | M2*10 | T6 |
| 3 | 34.00-43.00 | 800-08 T3 08M-C-G | M2.5*10 | T8 | 3 | 35.00-54.99 | 800-08 T3 08M-I-G | M2.5*10 | T8 |
| 4 | 43.01-47.00 | 800-10 T3 08M-C-G | M2.5*10 | T8 | 4 | 55.00-65.00 | 800-12 T3 08M-I-G | M2.5*10 | T8 |
| 5 | 47.01-49.99 | 800-12 T3 08M-C-G | M2.5*10 | T8 | |||||
| 6 | 50.00-57.99 | 800-10 T3 08M-C-G | M2.5*10 | T8 | |||||
| 7 | 59.00-65.00 | 800-12 T3 08M-C-G | M2.5*10 | T8 | |||||
 |
Boring dia | Center cutter seat | cutters | Nuts | Wrench |
| 63.50-82.55 |  |
TPMT 16 T3 12R-22 | M3*10 | T10 | |
| 107.95-130.00 | TPMT 16 T3 12TR-23 | M3*10 | T10 | ||
| 85.00-105.00 |  |
TPMT 22 06 12R-22 | M4*10 | T15 | |
| TPMT 22 06 12TR-23 | M4*10 | T15 |
 |
Boring dia | Center cutter seat | cutters | Nuts | Wrench |
| 63.50-90.00 |  |
TPMT 16 T3 12R-22 | M3*10 | T10 | |
| 107.95-130.00 | TPMT 16 T3 12TR-23 | M3*10 | T10 | ||
| 95.00-105.00 |  |
TPMT 22 06 12R-22 | M4*10 | T15 | |
| TPMT 22 06 12TR-23 | M4*10 | T15 |
 |
Boring dia | Center cutter seat | cutters | Nuts | Wrench |
| 63.50-82.55 |  |
TPMT 16 T3 12R-22 | M3*10 | T10 | |
| 107.95-120.65 | TPMT 16 T3 12TR-23 | M3*10 | T10 | ||
| 85.00-105.00120.00-130.00 | |
R424.9-18 06 08-22 | M4*10 | T15 | |
| R424.9-18 06 08-23 | M4*10 | T15 |
Mark: With “-22” items are normal slot cutters, with” -23” items are special slots cutters.
| Boring dia | Guide seats | Nuts | Wrench |
| 65.01-75.00 | ZJ65-012 | Flower M5*12 | T10 |
| 75.00-130.00 | ZJ85-012 | inner hexagon M5*12 | T10 |
The diameters bigger than 130mm are customized.
